IMAGING

Image Sensor: 1"-Type MOS
Effective Sensor Resolution: 15.03 Megapixel

Image Stabilization:
Optical in Integrated Lens
Digital

Built-In ND Filter: Mechanical Filter Wheel with 6-Stop (1/64), 2-Stop (1/4), 4-Stop (1/16), Clear ND Filters
Capture Type: Video Only

EXPOSURE CONTROL

Shutter Type: Electronic Rolling Shutter
Shutter Speed: 1/10000 to 1 Second
Shutter Angle: 3 to 360o

ISO/Gain Sensitivity
Native: 400 to 12,800
Gain: -3 to 36 dB

Precise Scan Rate Control: Yes

White Balance
Presets: Set B, ATW, Set A
Range: 2000 to 15,000K

LENS

Focal Length: 8.8 to 176mm (35mm Equivalent: 24.5 to 490mm)
Zoom: 20x Optical
Maximum Aperture: f/2.8 to 4.5
Filter Size: 67 mm

Control Rings
Iris
Zoom
Focus

FOCUS

Focus Mode: Automatic, Manual Focus

VIDEO CAPTURE

Internal Recording

H.264/MOV 4:2:2 10-Bit:
3840 x 2160 from 1 to 30.00 fps (150 to 200 Mb/s VBR)
1920 x 1080p from 1 to 60.00 fps (50 to 200 Mb/s VBR)
1920 x 1080p at 120 fps (100 to 400 Mb/s)
1920 x 1080i at 50/59.94 fps
*Sensor Crops During Recording

H.265 Long GOP/MOV 4:2:0 10-Bit:
3840 x 2160 from 1 to 60.00 fps (100 to 200 Mb/s VBR)

Video Output

4:2:2 10-Bit via HDMI:
3840 x 2160 at 25/29.97/50/59.94/23.98 fps
1920 x 1080p at 59.94/23.98/25/29.97/50 fps
1920 x 1080i at 59.94/50 fps
1280 x 720 at 59.94/50 fps

4:2:2 10-Bit via SDI/BNC:
1920 x 1080p at 50/59.94 fps
1920 x 1080i at 59.94/50 fps
1920 x 1080PsF at 23.98/25/29.97 fps
1280 x 720 at 59.94/50 fps

Broadcast Output: NTSC with 2000 TV Lines
Fast-/Slow-Motion Support: Yes
Gamma Curve: Panasonic V-Log, HDR-HLG
Built-In Microphone: Stereo

Audio Recording
MOV: 4-Channel, 24-Bit at 48 kHz via LPCM Audio
AVCHD: 2-Channel, 16-Bit at 48 kHz
MXF: 4-Channel, 24-Bit at 48 kHz via AAC LC Audio
MXF: 4-Channel, 16-Bit at 48 kHz

IP Streaming
H.264, RTSP, RTMP, RTP, RTMPS, SRT:
3840 x 2160 at 50p, 60p, 30p, 24p, 25p (0.5 to 75.00 Mb/s)

INTERFACE

Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-II) [V90 or Faster Recommended]

Internal Storage: No

Video I/O
1x BNC (12G-SDI) Output
1x HDMI 2.0 Output
1x 1/8" / 3.5 mm TRRS A/V (Composite) Output
1x RJ45 (NDI) Output

Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Line Input on Camera Body
1x XLR 3-Pin Mic/Line Input on Included Handle (+48 V Phantom Power)
1x XLR 3-Pin Mic/Line Input on Camera Body (+48 V Phantom Power)

Power I/O: 1x Barrel (12VDC) Input

Other I/O
1x BNC (Timecode) Input/Output
1x BNC (Genlock) Input
1x 2.5 mm Sub-Mini (Remote)
1x RJ45 (Ethernet, LAN) (Shared with Video Output)
1x USB-C (USB 3.2 / 3.1 Gen 1)
1x USB-A (USB 2.0) Host

Wireless: No

Mobile App Compatible
Yes: Android & iOS
App Name: CX ROP

Global Positioning (GPS, GLONASS, etc.): No

MONITOR

Display Type
Primary Monitor: Articulating 3.2" Touchscreen LCD

VIEWFINDER

Type: Electronic (OLED)
Resolution: 1,770,000 Dot

GENERAL

Battery: Panasonic AG-VBR Series
Power Consumption: <=26 W
Operating Conditions: 32 to 104oF / 0 to 40oC at 10 to 80% Humidity
Shoe Mount: 2x Cold Shoe
Built-In Video Light: No
Dimensions (W x H x D): 7.1 x 6.8 x 12.2" / 180 x 173 x 311 mm (Without Protrusions)
Weight: 4.2 lb / 1.9 kg (Body Only)

Panasonic 7.28V 43Wh Lithium-Ion Battery
Panasonic Battery Charger for AG-VBR
AC Adapter with Power Cord
Microphone Holder Kit
Shoulder Strap
Eye Cup
Lens Hood
Grip Belt
