Specifications
IMAGING
Image Sensor: 1/2.5"-Type MOS
Effective Sensor Resolution: 8.29 Megapixel
Image Stabilization: Digital
Built-In ND Filter: Mechanical Filter Wheel with 6-Stop (1/64), 2-Stop (1/4), 4-Stop (1/16), Clear ND Filters
Capture Type: Stills & Video
EXPOSURE CONTROL
Shutter Type: Electronic Rolling Shutter
Shutter Speed: 1/8000 to 1/6 Second in Movie Mode
Sensitivity: f/1.8 at 4 lux
Minimum Illumination: 1.5 Lux
White Balance
Range: 2000 to 15,000K
Presets: ATW, Auto
LENS
Focal Length: 4.12 to 98.9mm (35mm Equivalent: 25 to 600mm)
Zoom: 24x Optical
Maximum Aperture: f/1.8
Minimum Aperture: f/4
Filter Size: 62 mm
Control Rings
Zoom
Focus
FOCUS
Focus Mode: Automatic, Manual Focus
VIDEO CAPTURE
Internal Recording
MOV 4:2:2 10-Bit:
3840 x 2160 at 25/29.97/23.98 fps
1920 x 1080p at 23.98/50/25/29.97/59.94 fps
1920 x 1080i at 50/59.94 fps
MOV 4:2:0 8/10-Bit:
3840 x 2160 at 25/29.97/50/59.94/23.98 fps
MP4 4:2:0 10-Bit:
3840 x 2160 at 25/29.97/50/59.94/23.98 fps
MP4 4:2:0 8-Bit:
3840 x 2160 at 25/29.97/23.98 fps
1920 x 1080p at 23.98/50/59.94 fps
AVCHD 4:2:0 8-Bit:
1920 x 1080p at 50/59.94 fps
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps
Video Output
4:2:2 10-Bit:
3840 x 2160 at 25/29.97/50/59.94/23.98 fps
1920 x 1080p at 59.94/23.98/25/29.97/50 fps
1920 x 1080i at 59.94/50 fps
1280 x 720 at 59.94/50 fps
720 x 576p at 50 fps
720 x 480p at 59.94 fps
Fast-/Slow-Motion Support : Yes
Built-In Microphone: Stereo
Audio Recording: AVCHD, MP4: 2-Channel, 16-Bit at 48 kHz
IP Streaming
H.264, RTSP, RTMP, RTP, RTMPS:
1920 x 1080
1280 x 720
640 x 360
320 x 180
INTERFACE
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC (UHS-I) [512 GB Maximum]
Internal Storage: No
Video I/O: 1x HDMI Output
Audio I/O
2x XLR 3-Pin Mic/Line Input (+48 V Phantom Power)
1x 1/8" / 3.5 mm TRS Stereo Microphone Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O: 1x USB-C (9VDC at 3 A) Input
Other I/O
1x 2.5 mm Sub-Mini (Remote) Control
1x USB-C
Wireless: 5.8 GHz Radio/RF / 2.4 GHz Radio/RF
Mobile App Compatible
Yes: Android & iOS
App Name: HC ROP
Global Positioning (GPS, GLONASS, etc.): No
MONITOR
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD
VIEWFINDER
Type: Electronic (OLED)
Resolution: 1,770,000 Dot
GENERAL
Battery: Panasonic AG-VBR Series
Power Consumption: 12.3 W
Shoe Mount: 1x Cold Shoe
Built-In Video Light: No
Dimensions (W x H x D): 5.1 x 3.7 x 10.5" / 129 x 93 x 267 mm (With Included Lens Hood)
Weight: 1.87 lb / 0.85 kg (Body Only)
