Specifications
IMAGING
Image Sensor: 1/2.5"-Type MOS
Effective Sensor Resolution: 8.29 Megapixel
Image Stabilization: Optical in Integrated Lens
Built-In ND Filter: Mechanical Filter Wheel with 6-Stop (1/64), 2-Stop (1/4), 4-Stop (1/16), Clear ND Filters
Capture Type: Stills & Video
EXPOSURE CONTROL
Shutter Type: Electronic Rolling Shutter
Shutter Speed: 1/8000 to 1/24 Second
ISO/Gain Sensitivity: Gain: 0 to 30 dB
Minimum Illumination: 1.5 Lux at 1/30 Shutter Speed and f/1.8 Aperture
White Balance
Range: 2000 to 15,000K
Presets: ATW, VAR
LENS
Focal Length: 4.12 to 98.9mm (35mm Equivalent: 25 to 600mm)
Zoom: 24x Optical
Maximum Aperture: f/1.8
Minimum Focus Distance: From Front of Lens: 3.9" / 10 cm
Filter Size: 62 mm
Control Rings: Iris, Zoom, Focus
FOCUS
Focus mode: Automatic, Manual Focus
VIDEO CAPTURE
Internal Recording:
H.264 Long GOP/MOV 4:2:0 10-Bit
3840 x 2160 at 25/29.97/50/59.94/23.98 fps (100 to 200 Mb/s)
H.265 Long GOP/MP4 4:2:0 10-Bit
3840 x 2160 at 25/29.97/50/59.94/23.98 fps (72 to 100 Mb/s)
H.265 Long GOP/MP4 4:2:0 8-Bit
3840 x 2160 at 25/29.97/50/59.94/23.98 fps (72 Mb/s)
1920 x 1080p at 23.98/50/25/29.97/59.94 fps (50 Mb/s)
MOV 4:2:2 10-Bit
3840 x 2160 at 25/29.97/50/59.94/23.98 fps (200 Mb/s)
1920 x 1080p at 23.98/50/25/29.97/59.94 fps (50 to 200 Mb/s)
MOV 4:2:0 8-Bit
3840 x 2160 at 25/29.97/50/59.94/23.98 fps (100 to 150 Mb/s)
AVCHD 4:2:0 8-Bit
1920 x 1080p at 25/29.97/50/59.94/23.98 fps (17 to 25 Mb/s)
1280 x 720 at 50/59.94 fps (8 Mb/s)
P2 4:2:2/4:2:0 8/10-Bit
1920 x 1080p at 50/59.94 fps (24 to 50 Mb/s)
1920 x 1080i at 50/59.94 fps
1280 x 720 at 50/59.94 fps (12 to 25 Mb/s)
Video Output:
4:2:2 10-Bit via HDMI
3840 x 2160 at 25/29.97/50/59.94/23.98 fps
1920 x 1080p at 59.94/23.98/25/29.97/50 fps
1920 x 1080i at 59.94/50 fps
1280 x 720 at 59.94/50 fps
720 x 576p at 50 fps
720 x 480p at 59.94 fps
4:2:2 10-Bit via SDI/BNC
1920 x 1080p at 25/29.97/12.50/59.94/23.98 fps
1920 x 1080i at 59.94/50 fps
1920 x 1080PsF at 23.98/25/29.97 fps
1280 x 720 at 59.94/50 fps
Broadcast Output: NTSC, PAL
Fast-/Slow-Motion Support: Yes
Built-In Microphone: Stereo
Audio Recording:
MOV: 2-Channel, 24-Bit at 48 kHz via LPCM Audio
MP4: 2-Channel, 16-Bit at 48 kHz via AAC Audio
AVCHD: 2-Channel, 16-Bit at 48 kHz via AC-3 Audio
P2: 2-Channel, 24-Bit at 48 kHz via LPCM Audio
P2: 2-Channel, 16-Bit at 48 kHz via LPCM Audio
IP Streaming:
H.264, RTSP, RTMP, RTP, RTMPS
320 x 180 to 1920 x 1080 (0.5 to 24.00 Mb/s)
H.264, NDI|HX2
1280 x 720 to 1920 x 1080 at 50p, 60p, 30p, 25p (2.0 to 24.00 Mb/s)
INTERFACES
Media/Memory Card Slot: Dual Slot: SD/SDHC/SDXC/microP2 Hybrid
Internal Storage: No
Video I/O:
1x HDMI 2.0 Output
1x BNC (3G-SDI) Output
Audio I/O:
2x XLR 3-Pin Input on Included Handle
1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input on Camera Body
1x 1/8" / 3.5 mm TRS Stereo Headphone Output on Camera Body
Power I/O: 1x USB-C (9VDC at 3 A) Input
Other I/O:
1x 2.5 mm Sub-Mini (Remote)
1x USB-C (USB 2.0)
Wireless: Wi-Fi
Mobile App Compatible: Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.): No
MONITOR
Display Type: Primary Monitor: Articulating 3.5" Touchscreen LCD
GENERAL
Shoe Mount:
1x Cold Shoe on Included Handle
1x Cold Shoe
Tripod Mount: 1/4"-20 Female
Accessory Mounting Thread: 1x 1/4"-20 on Included Handle
Built-In Video Light: Yes
Dimensions (W x H x D): 10.5 x 6.3 x 5.1" / 267 x 159 x 129 mm (With Included Battery, Handle, Included Lens Hood)
Weight:
1.87 lb / 0.85 kg (Body Only)
3.3 lb / 1.5 kg (With Handle, Battery)
