Features
Format: HDV / DV SP / DV LP
LCD panel: 7.0 inch (16:9 widescreen)
Panel resolution: 1,152K dots 800(H) x 480(V) x 3RGB
All-scan function
User-assignable LCD setup profiles: 6 (settings for Brightness, Colour Level, Contrast, Sharpness, Colour, Phase)
Specifications
Inputs:
- i.LINK (HDV/DV)
- Video (RCA x1)
- Audio (RCA x2)
- S-Video
Outputs:
- HDMI
- i.LINK (HDV/DV)
- Component HD/SD (Special D)
- Video/Audio/S Video (AV Multi-connector)
- USB
- Memory Stick Slot
- Headphone jack
- Stereo speaker
- Battery: InfoLITHIUM L / M series
- DC power in
Recording Media MiniDV Cassette (sold separately)
Recording and Playback Times SP: 60 minutes, LP: 90 minutes (using DVM60 cassette available in Standard Definition only)
Video Actual High Definition: 1080i and 720p compatible Standard Definition: up to 530 lines
Still Actual Up to 1440 x 800
Video Recording System 2 Rotary Heads, Helical Scanning System
Video Signal System NTSC Standard
Recording Format Rotary Heads, 12 and 16 bit PCM System
LCD 7" (1152k Pixels)
Analog Audio/Video Input(s) Composite - In Only
Analog Audio/Video Output(s) Multi A/V (SD), Component (HD)
Digital Audio/Video Input(s) Yes (via i.LINK(R))
Digital Audio/Video Output(s) Yes (via i.LINK(R))
USB Port(s) Yes
i.LINK(R) Interface Yes
Headphone Jack Yes (Stereo Mini)
S-Video Input(s) Yes; Composite
S-Video Output(s) Yes; Multi A/V
HDMI(tm) Connection Output(s) Yes
Memory Stick PRO(tm) Media Compatibility Tested to support up to 8GB media capacity; does not support high speed transfer function; does not support Access Control function.
Still Image Mode(s) JPEG
Multiple Language Display Yes
Remote Control Remote Commander(R) (RMT-844)
PictBridge Compatible Yes
Dimensions (W x H x D) 201 x 63 x 162mm
Power Consumption High Definition: Record - 6.1/3.6W (LCD on/off); Playback - 6.5W/4.0W (LCD on/off) Standard Definition: Record - 6.1/3.6W (LCD on/off); Playback - 6.3W/3.8W (LCD on/off)
Battery Type InfoLITHIUM(R) Battery NP-F570
Operating System Compatibility Microsoft(R) Windows(R) 98, 98SE, ME, 2000, XP; Macintosh(R) 8.5.1, 8.6, 9.0, 9.1, 10.0, 10.13
Accessories Supplied Power Adapter (AC-L100), InfoLITHIUM(R) Rechargeable Battery (NP-F570), Remote Commander(R) (RMT-844), Component Video Cable, AV Cables, USB Cable
